WaterPro DSE130 Sump Pump 130L/min

WaterPro DSE130 Sump Pump 130L/min

Instruction
Manual

Exploded
View

The WaterPro Domestic Vortex Submersible pump is an economical solution for many sump, draining and sullage applications. Lightweight, efficient and high quality construction covered by a 12 month warranty.

Specifications

CODE 21071 MODEL DSE130
AMPS 1.9 WATTS 460
RATED FLOW 70 L/min RATED HEAD 3m
MAXIMUM FLOW 140 L/min MAXIMUM HEAD 6m
SOFT SOLIDS 5mm OUTLET 32mm
CABLE LENGTH 10m SIZE (mm) 160 x 190 x 325
WEIGHT 4.5

Features & Benefits

Solids handling 20mm
Max immersion depth of 5 metres
High performance
Integrated float switch, auto start/stop function
Thermal overload protection
10m power cable, H05RN-F
Includes 3 different hosetails – 25/32mm
Lightweight for ease of installation and maintenance high-wear mechanical seals for long service life in harsh environment
Electrical Safety Approval to AS/NZS60335.2.41

Construction

Stainless steel motor casing and shaft
Technopolymer vortex impeller with special sand-lifting design to reduce clogging and wear
High-grade, corrosion-proof NORYL PPO main body and base
Jointly sealed shaft with spring loaded seal ring and slide-ring axial seal
European adjustable depth float switch
Noryl base, outlet and hosetail
Ingress Protection IP68
Insulation Class F

Applications

Sump Drainage
Pool Emptying
Greywater pumping
Septic Systems (not for raw sewerage)
Stormwater
